Product features:
1. Purchase computer control systems and servo motors imported from Taiwan;
2.the computer is Chinese interface, easy to operate, accurate positioning, the computer can control three to eight servo motors, all motors can run synchronously or independently;
3. It is equipped with precision detection and tracking system. If there are unqualified products, the machine can stop automatically.
4. According to the working conditions on the fluorescent screen, the outer diameter Angle of the product can be corrected at any time;
5. Automatic lubrication and oil supply design of mechanical automatic parts ensures the long-term operation of the equipment;
6. When the wireless, wire breaking, wire winding automatic stop design and wire frame automatic acceleration function, so that the production more easily and effectively;
7.Suitable for the production of straight springs, pagoda springs, automotive springs, damping springs and other high demand springs.
Technical parameters：
Style | BLO-213 |
Wire Diameter | 3.0-10.0mm |
Maximum outside diameter | 140MM |
Number of Axes | 6 Axis |
The maximum feed length | infinite |
The maximum production speed | 150 pieces/min |
External diameter servo power (1) | 3.8kw |
External diameter servo power (2) | 3.8kw |
Machine Weight | 5800 KG |
Voltaae | 3AC 380V/50HZ |
Product features:
1. Purchase computer control systems and servo motors imported from Taiwan;
2.the computer is Chinese interface, easy to operate, accurate positioning, the computer can control three to eight servo motors, all motors can run synchronously or independently;
3. It is equipped with precision detection and tracking system. If there are unqualified products, the machine can stop automatically.
4. According to the working conditions on the fluorescent screen, the outer diameter Angle of the product can be corrected at any time;
5. Automatic lubrication and oil supply design of mechanical automatic parts ensures the long-term operation of the equipment;
6. When the wireless, wire breaking, wire winding automatic stop design and wire frame automatic acceleration function, so that the production more easily and effectively;
7.Suitable for the production of straight springs, pagoda springs, automotive springs, damping springs and other high demand springs.
Technical parameters：
Style | BLO-213 |
Wire Diameter | 3.0-10.0mm |
Maximum outside diameter | 140MM |
Number of Axes | 6 Axis |
The maximum feed length | infinite |
The maximum production speed | 150 pieces/min |
External diameter servo power (1) | 3.8kw |
External diameter servo power (2) | 3.8kw |
Machine Weight | 5800 KG |
Voltaae | 3AC 380V/50HZ |
